제품 상세 정보:
원래 장소: 치안스, 중국
브랜드 이름: Yixing ICS
인증: CE ISO SGS
결제 및 배송 조건:
최소 주문 수량: 1개 세트/세트
가격: $2,000.00 - $3,000.00 / Set
공급 능력: 내무반 당 50 세트/세트
접촉
상세 제품 설명
상태: 새롭습니다 온도: -45~+15
전압: 커스텀지드 20/380V 힘: 2.9KW
차원(L*W*H): 냉장실 차원 중량: 의존합니다
상품 이름: 냉장고 룸 OEM 기능: 냉동 식품 저장 / 블라스트 프리더
압축기 상표: 독어 Bitzer 문 유형: Hinged/Sliding/Swing/Return 문
패널의 간격: 50~200mm 컬러 스틸의 두께: 0.426/0.5/0.6/0.8 밀리미터
재료: 녹슬지 않는 / 칼라 강판 절연재: 폴리우레탄 샌드위치 절연제 패널
비중: 38~45kg/m3 캐릭터: 환경 친화적 / 에너지 절감
애프터 서비스는 제공되었습니다: 의 영상 기술지원, 온라인 지원 위임하고 훈련하고, 야전 정비 수리 업무 자유로운 예비 품목, 분야 임명 보증: 납품 후에 1 년

Product Description

Yixing ICS Cold Room

Choice in every part of our cold room:

1. Evaporator is divided into aluminum alloy pipe row and cold air blower.

2. Insulation layer thickness ranges from 50~220 mm, it also depends on the temperature of the cold room.

3. Material of our cold room plate: stainless steel/color steel/galvanized steel (inside or outside).

4. Brand of compressor: Bitzer/Bock/Fusheng/Hanzhong/Danfoss/Copeland etc.

We can customize the cold room totally as your demands.


Features and advantages

1. Concavo convex structure
Panels are joined together by means of tongue and groove and locked together by cam- lock on each side of the panel to ensure air tight joints. There's no need of rivets, thus reduce the cost and save the time.


2. Easier and faster installation,can be expended or removed in the future.



3. Perfect heat insulation
High density thermo insulated PUR foam up to 38kg/m³or above for perfect cold-room heat insulation efficiency.



4. Various surface steel choices.
Color steel sheet/Stainless steel sheet/ Embossed aluminum sheet
The standard metal sheets are all smooth. Standard color of steel sheet is white-gray, others are natural metallic.


5. Low flammable
Low flammable PUR foam is used in the cold room panel, with fire retardant B2 grade.



6. Highly hermetical
Silica gel are used on the panel edge of the joint parts of each sandwich panel to ensure perfect sealing to avoid the cooling air leakage from the cool room or moisture inside the PU insulated panel for the best refrigeration and frozen storage result.



7. Load bearing
The compressive strength is150kpa above, people can walk on the floor panels and allow trolleys can go in and out.

Cold Storage Ice Plant ice storage room 0
Cold Storage Ice Plant ice storage room 2


Main Features

1) Energy-saving design, high performance and efficiency, saving electricity in large degree.

2) Remote intelligent management system, automatic high precision digital controller is easy to operate with high efficiency.

3) Imported European compressor, low noise and high reliability, world renowned brand refrigeration accessories guaranteeing longer service life.

4) Adjustable indoor temperature, according to cooled products to adjust the most suitable temperature.

Cold Storage Ice Plant ice storage room 4
Detailed Information
Cold Storage Ice Plant ice storage room 6
Cold Storage Ice Plant ice storage room 8
Cold Storage Ice Plant ice storage room 10
Cold Room Temperature
1~5 degree
Fresh Keeping Room
Preservation of fresh meat, dairy products, fresh eggs, fruits and vegetables
-10~-20 degree
Cold Storage Room
Mainly used for refrigerating food, and the temperature is kept in the range of -15~18 degree
-22~-25 degree
Low Temperature Room
Mainly used for refrigerating food, and the temperature is kept in the range of -15~18 degree
<-30 degree
Cold Freezer
Mainly used for quick freezing of foods, such as quick frozen dumplings, quick frozen vegetables, etc.
Cold Storage Ice Plant ice storage room 12
Related Products
Cold Storage Ice Plant ice storage room 14
Cold Storage Ice Plant ice storage room 15
Cold Storage Ice Plant ice storage room 17

Evaporative Condenser

97% Response Rate

Cold Room

98% Response Rate

Air Cooler

99% Response Rate

Our Service
Cold Storage Ice Plant ice storage room 19

Pre-Sales Service

* Inquiry and consulting support.
* Sample testing support.
* View our Factory.

After-Sales Service

* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.

Packing & Delivery
Cold Storage Ice Plant ice storage room 21
Cold Storage Ice Plant ice storage room 23
Cold Storage Ice Plant ice storage room 25
Activities
Cold Storage Ice Plant ice storage room 27
Cold Storage Ice Plant ice storage room 29
About Yixing ICS

Yixing city Ice Source Refrigeration Equipment Limited is a comprehensive mordern manufacture of all kinds ice making plants, cold room, high-efficiency cold air blower, energy-saving evaporative condenser, aluminum alloy pipe row and various civil constructions, combined with cold room engineering.


ICS is located in Yixing, Wuxi, Jiangsu, CHINA. With over 20 year's successful experience in Chinese market, we focus on the technical innovation to improve the machine quality and strengthen innovation ability. By insisting on the spirit "unity, seeking truth, pioneering and dedication", we commit ourselves to research and development of new technology, striving to create a comprehensive refrigeration enterprise in China.

Cold Storage Ice Plant ice storage room 31
Certifications

CE Certificate Number:

M.2019.206.C0141

Cold Storage Ice Plant ice storage room 33
